| General Specification | |
| Panel size | 19-inch TFT-LCD |
| Standard Resolution | 1280*1024 |
| Number of Colors | 16.7M |
| Brightness | 300cd/m2 |
| Response time | 5ms |
| View angle | Horizontal:160; Vertical:150 |
| Contrase ratio | 1000:01:00 |
| Video input format | (analog) RGB |
| Connector | VGA(AV/TV/HDMI optional) |
| Video input connection | Mini D-Sub 15 Needles VGA |
| Frequency | 30~80KHz/60~75Hz |
| Power supply | DC 12V (100-240V AC 60/50Hz optional) |
| Power consumption | Max 30W |
| Setup (optional) | 1) provide wall brackets for wall-mounted,VESA 75mm&100mm |
| 2) provide stable mental base to support the monitor | |
| OSD control | AUTO,+,POWER,-,MENU |
| brightness,contrast ratio,auto adjustment,phase position, clock, Languages,function,Install,reset | |
